Big Tex General Duty Low Profile Dump Trailer | 14LD-14BK

14ET Heavy Duty Tandem Axle Equipment Trailer

Description:
\nEngineered to handle the toughest hauling and equipment transportation tasks, the 14ET Heavy Duty Tandem Axle Equipment Trailer delivers unmatched versatility, durability, and strength. Ideal for construction professionals, landscapers, farmers, and anyone requiring heavy-duty hauling, this trailer combines a rugged frame, reinforced deck options, and premium suspension to tackle long, demanding hauls with ease. With multiple tie-down points, recessed LED lighting, heavy-duty ramps, and optional storage solutions, the 14ET is designed to maximize both efficiency and convenience.

Standard Features:

\n
• Axles: 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
\n
• Brakes: Forward Self-Adjusting Electric Brakes on Both Axles
\n
• Suspension: Multi-Leaf Slipper Spring with Equalizer
\n
• Coupler: 2-5/16″ Ball, Adjustable Demco EZ Latch Coupler (Bumper Pull); 2-5/16″ Round Gooseneck Coupler (Gooseneck models)
\n
• Safety Chains: 3/8″ Grade 70 with Safety Latch Hook (2 ea)
\n
• Jack: 12,000# Drop-Leg Jack (Side Wind); Dual Jacks on Gooseneck Models
\n
• Frame: 6″ Channel Cross-Members 3″ Channel on 16″ Centers
\n
• Front Stop Rail: 3/16″ Fabricated Front Stop Rail (Bumper Pull Only)
\n
• Floor Options: APEX Fortified Lumber, Blackwood Pro Rubber Infused Lumber, 1/8” Diamond Plate Steel Floor
\n
• Fenders: 9″ x 72″ 14 Ga. Diamond Plate Double Broke with Back
\n
• Ramps: 4’ Tall, 16″ Knee Ramps (Spring Assisted), 44″ Wide Mega Ramps (Dovetail only), 5′ Rear Slide-In Ramps (Straight Deck models), Super-Wide Ramps (60″ Tall x XX” Wide)
\n
• Dovetail: 3′ Cleated Dovetail, Blackwood Pro Dovetail (Standard with Super-Wide Ramps)
\n
• Stake Pockets: Along Both Sides (Quantity Varies by Length)
\n
• Trailer Plug: 7-Way RV Lights, Recessed, Grommet-Mounted LED Lighting
\n
• Wiring: Sealed, Modular Cold-Weather Wiring Harness
\n
• Tires: ST235/80 R-16 Load Range E Radial Tires; Tire Upgrade Available (ST235/80 R-16 LR-G)
\n
• Bolt Pattern: 8-Lug Wheels, Black Mod Steel
\n
• Spare Mount: Front Spare Tire Mount; Spare Tire & Wheel Optional
\n
• Paint Colors: Black, Red, Grey, White, Desert Tan, Jet Blue, Slime Green, Implement Green, Equipment Orange, Medium Yellow
\n
• Rubrail: Along Both Sides
\n
• Tie-Downs: (6) 5/8″ D-Rings; Extra 5/8″ D-Rings; Recessed D-Ring in Floor (Steel Floor Only)
\n
• Break-Away Kit: Complete Breakaway System with Zip Breakaway Cable
\n
• Storage: Tongue Tool Tray (Bumper Pull Only), Lockable Toolbox Between Risers (Gooseneck Model)
\n

Models & Specifications:
