Big Tex Single Axle Vanguard Trailer | 35SV

The 90SR Tandem Axle Single Ram Dump Trailer is built to make hauling and dumping easier, faster, and more efficient for homeowners, farmers, and hardworking operators. Designed with a straight ram hydraulic lifting system, this durable dump trailer handles mulch, dirt, gravel, and other heavy materials with reliable dumping performance and rugged construction.

Built for strength and versatility, the 90SR features tandem 5,200 lb. premium cambered axles, forward self-adjusting electric brakes, and a heavy-duty rectangular tubing frame for dependable towing and hauling capability. The 20-inch tall 12-gauge steel sides and 12-gauge smooth steel floor provide excellent durability for demanding work environments.

For added convenience, the trailer includes a lockable pump and battery box, recessed LED lighting, sealed cold-weather wiring harness, integrated D-rings, stake pockets, and double rear doors for easy loading and unloading. An optional slide-in ramp package also allows users to transport small equipment when needed.

Features:

\n
• Tandem axle single ram dump trailer
\n
• Power up/power down hydraulic dump system
\n
• Self-contained single cylinder lift ram
\n
• Heavy-duty steel construction
\n
• 20 in. tall 12-gauge steel sides
\n
• 12-gauge smooth steel floor
\n
• Tandem 5,200 lb. premium cambered axles
\n
• Forward self-adjusting electric brakes
\n
• Multi-leaf slipper spring suspension with equalizer
\n
• Lockable pump and battery box
\n
• Recessed LED lighting system
\n
• Sealed modular cold-weather wiring harness
\n
• Stake pockets along both sides
\n
• Integrated 1/2 in. D-rings for cargo security
\n
• Double rear doors for convenient unloading
\n
• Optional 6.5 ft. slide-in ramp package
\n
• Professional black finish with primer
\n

Specifications:

Model 90SR-12

\n
• Pull Type: Bumperpull
\n
• GVWR: 9,990 lbs.
\n
• GAWR (Each Axle): 5,200 lbs.
\n
• Empty Weight: 2,930 lbs.
\n
• Cargo Capacity: 7,060 lbs.
\n
• Bed Length: 12 ft
\n
• Bed Width: 72 in.
\n
• Tongue Length: 45 in.
\n

Model 90SR-10

\n
• Pull Type: Bumperpull
\n
• GVWR: 9,990 lbs.
\n
• GAWR (Each Axle): 5,200 lbs.
\n
• Empty Weight: 2,750 lbs.
\n
• Cargo Capacity: 7,240 lbs.
\n
• Bed Length: 10 ft
\n
• Bed Width: 72 in.
\n
• Tongue Length: 45 in.
\n

Additional Specifications:

\n
• Tires: ST225/75 R-15 Load Range D Radial Tires
\n
• Coupler: Adjustable Forged Coupler
\n
• Floor Material: 12 Gauge Smooth Steel
\n

Available now at Stoolby.com
